  • CGN208-D Semi-auto Capsule Filling Machine

    Descriptions:
    It''s suitable for filling powder and granular material in pharmacy and health food industry.
    This machine has independent empty capsule feeding station, powder feeding station and capsule closing station. The medium process needs to be processed by hand. The machine adopts variable speed control, the operation is very easy and simple, and the powder material feed correctly. The machine body and working table adopt S.S. material; meet the sanitary requirement of pharmacy.

    Technical Parameters

    The time of replacing debugging mold

    5-8mins(for beginners)

    Production rate

    1-2.5 ten thousand/hour(depending on capsules No.)

    Applicable capsules

    000#,00L#,00#,0#,1#,2#,3#,4#,Mechanism standard capsules

    Filling material

    Without a sticky and wet powder,small granules

    Total power

    4.0kw

    Air pressure

    0.03m^3/min 0.6Mpa

    Vacuum pump

    Pump capacity is 40m^3/h

    Machine dimension

    1140*700*1630mm

    Packing dimension

    1650*800*1750mm

    Net weight

    350kg

    Gross weight

    380kg

  • NJP Series Auto Capsule Filling Machine

    Application:

    Used for pharmaceutical, medicine, and chemicals (powder, Pellet, granule, pill) vitamin, foodstuff and animal drug, etc.

    Features:

    1.Touch-Screen, PLC program control panel with LCD.

    2.The capsule qualified over 99%.

    3.Removable powder hopper allows easy cleaning and auger adjustment allows change fills weight easily.

    4.Speed and length of closed capsule are easy to adjust.

    5.Electrical Appliance control system is in accordance with CE and international standards.

    6.At the quick and accurate change part,easily and removable rotary table and ring carrier assembly is setted.

    7.Fully enclosed rotary table and dosage station for integration of the whole capsule filling plants.

    8.Large cam mechanism keeps the rotating table of mould together with the whole equipment running in balance, and completely guarantees the machine operating with highest precision and accuracy.


    Technical Parameters

    Model

    NJP-200

    NJP-400

    NJP-800

    NJP-1200

    NJP-2300

    NJP-3500

    Capacity(Capsules/h)

    12000

    24000

    48000

    72000

    138000

    210000

    Machine weight(kg)

    700

    800

    900

    1100

    1500

    2200

    Overall dimension(mm)

    610*680*1800

    760*780*1800

    840*820*1900

    860*940*1900

    1010*1080*2000

    1170*1560*2000

    Power supply

    380/220V 50Hz

    380/220V 50Hz

    380/220V 50Hz

    380/220V 50Hz

    380/220V 50Hz

    380/220V 50Hz

    Total power(KW)

    3

    3

    4

    5

    8

    10.5

    No.of segment bores

    2

    3

    6

    9

    18

    25

    Vacuum

    20m^3/h-0.04-0.08Mpa

    40m^3/h-0.04-0.08Mpa

    63m^3/h-0.04-0.08Mpa

    120m^3/h-0.04-0.08Mpa

    Making rate

    Empty capsule 100%Full,capsule over 99%

    Suitable for capsule

    00,0,1,2,3,4,5#

    Filling error

    ±2.5%-±3.5%

  • HLSG Series High Granulator

    Application
    It''s applied for power mixing, granulation and binder in pharmaceutical, chemical and food fields.

    Features
    Adopt frequency speed adjustment to control the stirring blade and cutter, easy to control the size of particle.  With the rotating shaft hermetically filled with air, it can prevent all dust from compact. With a structure of conical hopper tank, all material can be in uniform rotation. The tank is laid with an interlayer on the bottom, in which water cooling circulation system featuring higher thermostatic performance than air cooling system is furnished, which leads to improve the quality of particles. With automatic lifting of the pan cover, the tank outlet matching with drying device, self-equipped arm-ladder, it is easy to operate. Lifting system with paddle is more beneficial to clean paddles and pot body.

    Technical parameters

    Model

    HLSG-10

    HLSG-50

    HLSG-100

    HLSG-200

    HLSG-300

    HLSG-400

    HLSG-600

    Working capacity

    2-8

    12-35

    25-70

    80-120

    130-180

    150-240

    75-360

    Time of Granulating/batch

    (Mixing:about 2minutes,Granulaion:about 7mintues/batch)

    Rotating Speed of Stirring Paddle(rpm)

    50-500

    25-500

    30-250

    30-250

    30-220

    30-200

    30-200

    Power of stirring motor (kw)

    2.2

    5.5

    7.5

    15

    18.5

    22

    30

    Rotating Speed of Cutter(R/M)

    50-3000

    50-3000

    50-3000

    50-3000

    50-3000

    50-3000

    50-3000

    Power of Cutting knife motor(KW)

    0.75

    1.5

    3

    4

    7.5

    11

    11

    Overall dimension (L×W×H)(mm)

    1350X540

    X1300

    1935X662

    X1575

    2078X702

    X1720

    2268X910

    X2010

    2600X1000

    X2130

    2870X1182

    X2560

    2900X1300

    X2600

    Height of Discharge Outlet(mm)

    796

    796

    796

    920

    985

    985

    985

    Weight(Kg)

    330

    400

    700

    1100

    1350

    1700

    2300



  • DPH-260 Automatic Blister Packing Machine

    Descriptions
    1. This Blister Packaging Machine can be packed separately to accommodate a lift having a 2.2m width, and delivered to the divided purification workshop.
    2.It is suitable for plastic thermoforming and aluminum cold forming blister packaging.
    Adopts positioning formats for straightforward format changeover.
    3.Add an optional perforation station, to separate the perforation from the embossing station. Conventionally, perforation and embossing remain in one station, but this will influence the clarity of each.
    4.Separation of drive and operating zones are in compliance with pharmaceutical GMP requirements.
    5.Material drag system adopts a precise servo motor to achieve stable, accurate running allowing blister length to be set freely.

    Main Technical Parameters

    Model

    DPH260H

    CapacityCycle/min

    100-200

    Range of strokemm

    20-120

    Maxforming area and depthmm

    260×250×12

    Packing material

    Pharmacy PVCmm

    0.2-0.4×260mm

    PTP alu foilmm

    0.2-0.4×260mm

    Clean compressed airpressure

    0.6-0.8MPA

    Power

    AC380V  50HZ  15.5KW

    Water chiller for moulds

    Tap water or recycle water

    with 60L/h consumption

    Overall dimensionL×W×H(mm)

    4860×1070×1750

    Net weihgtkg

    3000

  • ZH-100 Cartoning Machine

    Product Description:
    The machine suitable for automatic feeding and packing products such as ALU-PVC Blister, bottle, cosmetics, commodity, hardware, card, and some other similar products into the carton. Adjust automatic feeding structure conveniently, randomly setup the quantity of blisters on touch screen. Online products feeding and detecting, leaflet folding(1-4 folds) and feeding, leaflet detecting, carton opening and forming, products and leaflet pushing into carton, printing lot number, sealing carton with tuck-in or hot melt glue device. Automatic reject lacking of package products and leaflet and convey the finished products. The machine can be used single or joint with pillow-type packing machine or other equipment for a production line.

    Features:
    Adopt International famours brand of electrical component such as PLC, Frequency inverters, etc.
    Adopt Human-machine operation system.
    Servo feeding suitable for different specification Alu-PVC blister. Automatically stop when machine is overloaded.
    Autoamatically reject lacking of package products and leaflet.
    Automatically display trouble, alarm and counting.
    Stable performance, easy operation.

    Technological parameter

    Model

    ZH-100

    Speed

    50~100boxes/min

    Box

    Quality requirement

    250~350g/m 2 (according to the dimensions to confrim)

    Dimension(L × W × H)

    (70-180)mm × (35-85)mm × (14-50)mm

    Leaflet

    Quality requirement

    60-70 g/m 2

    Unfolded leaflet Specification

    (80-250)mm × (90-170)mm

    Folded Leaflet Specification

    1-4 fold

    Compressed air

    Working pressure

    ≥ 0.6mpa



    Air consumption

    20m 3 /h

    Power Supply

    380V 50HZ

    Motor power

    0.75kw

    Machine Dimension(L × W × H)

    3100 × 1100 × 1550MM

    Weight

    1400kg

  • WTU-1 Semi-automatic Packing Machine

    Product Description
    The semi-automatic multifunctional pillow packing machine was made according to the American Restaurant Association Requirements. The machine is widely used in cutlery,dishes,bread,and other different kinds of products, It is suitable for all kinds of films,like BOPP,OPP,CPP and so on, it owns a advantage of wide range of applications, small footprint, high safety performance, light weight and low price. It’s the first choice for cottage enterprise with low-volume packaging.

    Technical Parameters

    Model

    WTU-1

    Finished package size

    Unlimited

    50mm-280 mm

    <65 mm  (can be customized)

    Packing Speed

     10-30 Bags/min

    Power specification

    220V/1500W

    (According to customer requirements)

    Machine weight

    85kg

    Dimension (L*W*H)

    536mm*540mm*820mm
